IMA Novimat Concept /I/G/80/650/R3 Edgebanding machine

IMA Novimat Concept /I/G/80/650/R3 Edgebanding Machine

Basic Data

Manufacturer: IMA

Model: Concept I/G/80/650/R3

Machine No.: 08113

Year of Manufacture: 2006

Weight: approx. 9700 kg

Condition: Used, inspected

Working Range: 3 mm

Table Passage Height: 800 mm

Total Power: 41 kW

Plasma: available

Return System: available



Machine Description



• Adjustable Fence 700.080

• Infeed Table 63.152

• Milling Units: 08.378 and 08.0555

• Glue Level Monitoring available

• Glue Application Unit 04.0832

• Gluing Unit 04.1570

• PU Pre-melter 283.203

• HK Tool Holder for high-speed motors

• End Trimming Unit 08.42

• Multi-Processing Unit 08.348

• Multi-Profile Scraper Unit 08.516

• Flat Scraper 08.517

• Copy Corner Buffing 08.604

• Buffing Unit 08.617-4

• Safety Devices: Light barriers, temperature controllers, control terminal

• Additional Equipment: Attached Roller Conveyor Table

• Extraction System included

• Total Machine Length: approx. 11–16 m



Main Units & Equipment

Adjustable Fence 700.080

Purpose: Precise positioning of workpieces for feeding into the machine.

Description: Horizontally manually adjustable, unheated, with guide carriage and adjustment spindle. Mechanical digital display for precise positioning.

Infeed Table 63.152

Purpose: Introducing wide or short workpieces at an exact angular position.

Description: Pneumatically retractable fence with safety shutdown. Sturdy aluminum tabletop, queried by limit switch.

Technical Data: Workpiece min. approx. 150 × 350 mm, max. approx. 600 × 1500 mm.

Milling Unit 08.378

Purpose: Processing the side narrow edges with milling tools in climb and conventional milling modes.

Description: Precision prismatic guides, adjustment via spindles and digital displays, extraction hoods for each tool. Three-phase flat motor with reinforced bearings and DC brake.

Glue Application Unit 04.0832

Purpose: Applying hot-melt adhesive to workpiece edges for bonding with edge material.

Description: Melting tank with large heating surface for fast heating. Electronic temperature control, thermostatically switched drive motor, automatic start and stop function.

PU Pre-melter 283.203

Purpose: Pre-melting polyurethane hot-melt adhesive and automatic filling of the glue container.

Description: Compact pre-melting unit with Teflon coating. Level control via level sensor with indicator light. Gentle temperature control for glue blocks.

End Trimming Unit 08.42

Purpose: Trimming front and rear edge overhang, flush or chamfered.

Description: Two units on prismatic guides, automatic adaptation to workpiece thickness, pneumatic feed. Optional right-angle or chamfered cuts up to 25°.

Multi-Processing Unit 08.348

Purpose: Radius and fine milling of the top and bottom edge, as well as copying processing on the front and rear edge.

Description: Precision guides with backlash-free movement, motorized adjustment, automatic adaptation to different workpiece shapes. Electronically controlled processing cycle.

Multi-Profile Scraper Unit 08.516

Purpose: Re-scraping profiles and radii without tool change.

Description: Compact design, electro-pneumatic adjustment, profile scraper set at a 30° angle. Self-sensing for top and bottom edges, with separate extraction.

Flat Scraper 08.517

Purpose: Removing hot-melt adhesive residue on the top and bottom edges.

Description: Top and bottom edge unit on a common stand, height sensing, air nozzles, electro-pneumatic disengagement.

Copy Corner Buffing 08.604

Purpose: Finishing edges in the area of the front and rear edge and at the top and bottom corners.

Description: Motor on pivot lever for combined lifting and pivoting movement, automatic adjustment via top pressure, pneumatic lifting movement. Buffing motors controllable and adjustable.

Buffing Unit 08.617-4

Purpose: Cleaning and polishing the top and bottom workpiece edges.

Description: Four buffing discs (2 top, 2 bottom), horizontally and vertically adjustable, mounted at 15°. Automatic adaptation to workpiece thickness. Optional with holder for separating and cleaning agents.

Safety Devices

Description: Comprehensive protection through light barriers, temperature controllers, and a central control terminal.



Accessories

Edge Magazines

Purpose: Stocking rolls of edge material for continuous processing.

Description: Two mobile sliding magazines, each for 12 rolls. Quick roll change possible.

Plasma Edge Heating Plasmatreat Düstec

Purpose: Activating the edge surface for better adhesive adhesion.

Description: Two plasma devices with central control cabinet. Proven Düstec technology for consistent results.

Panel Return System VENJAKOB

Purpose: Automatic return of workpieces for multiple processing steps.

Description: 7 belt conveyor tables (100 cm width), 1 round belt table, 2 angled transfer tables, control cabinet system. Efficient material handling for high productivity.

Periphery Items

Purpose: Integration and control of the edge processing line.

Description: Interface system for plant connection, barcode scanning system for automated workpiece identification.
