OMLAT Homag Main Spindle 12 KW 2-056-09-9670 and RENISHAW Measuring Probe Motor Spindle with C-axis Item No. 2055060

OMLAT Homag Main Spindle 12 KW  2-056-09-9670 and RENISHAW Measuring Probe Motor Spindle with C-axis Item No. 2055060

The high-performance OMLAT main spindle offers you a precise and powerful solution for your CNC machining requirements. This used spindle was removed from a running system and still offers excellent performance and reliability.

Please contact us if you only need the spindle and not the additional units. We also have a spindle in stock that can be offered without a C-axis and measuring probe.

Technical specifications:

• Tool holder: HSK F63, taper diameter 38 mm, similar to DIN 69893
• Tool clamping: Automatic with a clamping force of 11,000 N
• Maximum tool weight: 6 kg
• Direction of rotation: Clockwise/counter-clockwise, programmable
• Speed range: Stepless 1,500 - 18,000 rpm, programmable
• Drive: Frequency-controlled three-phase motor
• Drive power: 12 kW in S-1 operation
• Spindle lubrication: One-time factory grease lubrication
• Spindle cooling: Water cooling
• Constant power: From 12,000 to 18,000 rpm
• Serial number: 006186
• Homag part number: 2056099670

Renishaw MP 11 Measuring Probe

The Renishaw MP 11 measuring probe is an indispensable addition to your CNC machine. It enables high-precision measurements and ensures that your machining processes are always exact and reliable.

Technical Data and Summary:

Summary: The Renishaw MP 11 is a probing system designed for CNC machining centers with manual tool change capability. It offers significant productivity gains by reducing setup times and improving precision in component inspection. This probe features direct signal transmission to the CNC machine control, visual indication of the probe status, and external spring force adjustment of the probe. The system includes various shank options for different machine types and configurations.

Technical data:

• Probe lengths: 36.5 mm, 21.5 mm, 8 mm
• Measuring directions: ±X, ±Y, +Z
• Trigger forces:
  • X and Y directions: 0.50 to 1.5N
  • Z direction: 1.8 to 7.0N
• Unidirectional repeatability: 1.0µm at 1000mm/min with a 50mm long stylus
• Dimensions:
  • X/Y overtravel: ±17.5°
  • Z overtravel: 8 mm
  • Probe diameter: Ø60 mm
  • Stylus diameter: Ø6 mm
• Cable length:
  • Coiled: 765 mm
  • Extended: 1695 mm
• Power supply: 15 - 30V DC, 100 mA max
• SSR contacts: ±50V DC, 50mA max
• Features:
  • Direct signal transmission
  • Visual display of probe status
  • External spring force adjustment of the probe
  • Probe alignment to the spindle center

NC-controlled C-axis (W-axis)

The NC-controlled C-axis (W-axis) significantly expands your machining capabilities. This axis enables a 360° rotating movement and is perfectly matched for use in Homag/Weeke machines.

C-axis features:

• Rotary motion: 360° NC-controlled
• Drive: Powerful motor for precise movements
• Reference pins: For exact positioning and repeatability

With this combination of high-performance main spindle, Renishaw MP 11 measuring probe and the NC-controlled C-axis (W-axis), you are optimally equipped for demanding machining tasks. These used components offer you maximum precision, reliability and flexibility in your production.
