OMLAT IMA main spindle 12 KW motor spindle electric spindle

High performance main spindle OMLAT 12 KW HOMAG

The OMLAT heavy-duty main spindle offers you a precise and powerful solution for your CNC machining needs. This used spindle was taken from a running system and continues to offer excellent performance and reliability.

Technical specifications:

• Tool holder: HSK F63, taper diameter 38 mm, similar to DIN 69893

• Tool feed: Automatic with a feed force of 11,000 N

• Maximum tool weight: 6 kg

• Direction of rotation: clockwise/anticlockwise, programmable

• Speed ​​range: Continuously adjustable from 1,500 to 24,000 rpm, programmable

• Drive: Frequency-controlled three-phase motor

• Drive power: 12 kW in S-1 operation

• Spindle lubrication: One-time grease lubrication

• Spindle cooling: Water cooling for optimal temperature control

• Constant power: From 12,000 to 24,000 rpm

• Serial number: 991263 (information subject to change as taken from the type plate)

Features and Benefits:

• OMLAT IMA main spindle: This high-performance spindle has been specially developed for demanding industrial machining solutions.

• 12 kW spindle: With an impressive drive power of 12 kW in continuous operation (S-1), this spindle offers the necessary power for intensive machining processes.

• Precision spindles: The spindle offers high precision and reliability, ideal for precise machining tasks.

• Automatic tool retraction: The automatic tool retraction with a retraction force of 11,000 N ensures efficient and safe work.

• Water cooling spindle: The integrated water cooling ensures optimal temperature control and extends the service life of the spindle.

• HSK F63 spindle: The HSK F63 tool holder enables safe and precise tool fastening.

• Compatibility: The main spindle and motor are perfectly suited for use in machines such as BA Z 32 and BOF 32. They are also versatile for other applications.

NC-controlled C-axis (W-axis):

The NC-controlled C-axis (W-axis) significantly expands your machining options. This axis enables 360° rotation and is perfectly suited for use in Homag/Weeke machines.

Properties of the C-axis:

• Rotation: 360° NC-controlled

• Drive: Powerful motor for precise movements

• Reference bolt: For exact positioning and repeatability

Flexible configuration:

• Industrial machining solutions: Perfect for a wide range of industrial applications, this spindle offers reliable performance and precision.

• Machine accessories: In addition to the main spindle, we also offer various machine accessories to further optimize your machining processes.

Experience the power and precision of the OMLAT high-performance main spindle and expand your machining options with the NC-controlled C-axis. Perfect for demanding industrial machining solutions.
